Adam 4500 Communication Controller
Specifications
• CPU: 80188-40
• Flash ROM: 256 KB (170 KB free memory for users)
• Operating system: Boot ROM DOS
• Timer BIOS: Yes
• SRAM: 256 KB (234 KB free memory for users)
• Real-time clock: Yes
• Watch dog timer: Yes
• COM1: RS-232/RS-485
• COM2: RS-485
• Program download port(RS-232): Tx, Rx, GND
• Power: Unregulated 10 to 30 VDC
• Power consumption: 2.0 W
• Operating temperature: -10 to 70° C (14 to 158° F)
• Case: ABS with captive mounting hardware
• Plug-in screw terminal block: accepts 0.5 mm to 2.5 mm
1-#12 or 2-#14 ~ #22 AWG
• Dimension: 60 mm x 120 mm (2.36″ x 4.41″)
