4500 Adam PC Based Communication Controller

Adam 4500 :

The ADAM-4500 is a fully functional, stand-alone controller for industrial automation and control. Its built-in ROM-/DOS (MS-DOS equivalent) operating system lets the user run either standard PC language development tools. One of its two communication ports can be configured as an RS-232 or RS-485 port, depending on jumper settings. The other port is a dedicated RS-485 port, allowing the controller to function in 2-wire, multi-drop RS-485 networks. With communication speeds up to 115.2 Kbps, a real-time clock, a watchdog timer, 256 K ROM, 256 K RAM, and panel or DIN-rail mounting, this device is a flexible, powerful unit in a small package.

Applications
• Embedded control applications
• Distributed data acquisition and control
• Laboratory data collection and process control
• Production monitoring and control

Features
• Powerful communication controller in a small package
• Built-in Boot ROM DOS to run PC programs
• Free ROM/RAM memory for user’s applications
• 2-wire, multi-drop RS-485 networking
• Communication speed up to 115.2k baud rate
• RS-232/RS-485 modes (jumper selectable)
• Automatic data flow control in RS-485 mode
• Built-in real-time clock and watchdog timer
• Easy mounting on a DIN-rail or panel
• Accepts unregulated power sources between 10 to 30 VDC
• Program download cable and utility included
